Clinical application effects of the "three-source and four-line method" in the design and harvest of anterolateral lower leg perforator flaps
-
摘要:
目的 探讨“三源四线法”在小腿前外侧穿支皮瓣设计与切取中的临床应用效果。 方法 该研究为回顾性病例系列研究。2023年8月—2024年7月,苏州瑞华骨科医院手外科收治24例、足踝外科收治6例符合入选标准的手、足创面患者,其中男22例、女8例,年龄18~58岁。清创后单个创面面积为2.0 cm×1.5 cm~15.0 cm×4.5 cm。采用“三源四线法”,将腓骨小头与外踝尖的连线记为C线,即腓骨的体表标志线；C线向前侧平移1.5 cm记为B线,即腓浅动脉穿支皮瓣的轴心线；C线向前侧平移3.0 cm记为A线,即胫前动脉穿支皮瓣的轴心线；C线向后侧平移1.5 cm记为D线,即腓动脉穿支皮瓣的轴心线。另使用彩色多普勒超声探测仪分别沿着A、B、D线探测3种来源的穿支,以此设计和切取小腿前外侧穿支皮瓣修复创面。共切取皮瓣35块,单块皮瓣切取面积为2.5 cm×2.0 cm~16.0 cm×5.0 cm。将供区创面均直接拉拢缝合。术中记录实际使用穿支的总数量,不同来源穿支的数量、口径及血管蒂长度,穿支入皮点至其相应轴心线的垂直距离。术后观察皮瓣成活情况。随访记录皮瓣色泽、质地和外形情况及供区瘢痕情况。末次随访时,使用皮瓣综合评价量表评定皮瓣修复效果,并计算皮瓣修复效果的优良率。 结果 术中实际使用穿支38条。其中,6条穿支来源于胫前动脉,口径平均0.47 mm；血管蒂长度平均4.33 cm；穿支入皮点至A线的垂直距离平均0.48 cm。20条穿支来源于腓浅动脉,口径平均0.51 mm；血管蒂长度平均5.25 cm；穿支入皮点至B线的垂直距离平均0.54 cm。12条穿支来源于腓动脉,口径平均0.72 mm；血管蒂长度平均4.13 cm；穿支入皮点至D线的垂直距离平均0.43 cm。术后所有皮瓣顺利成活。术后随访6~15个月时,皮瓣色泽良好、质地柔软、外形无明显臃肿,供区仅遗留线性瘢痕。末次随访时,皮瓣综合评价量表评分为82~94分,皮瓣修复效果的优良率为100%（35/35）。 结论 “三源四线法”具有操作简便、定位准确等优势,有助于小腿前外侧穿支皮瓣术前灵活设计、术中安全切取,具有较高的临床应用价值。 Abstract:Objective To explore the clinical application effects of the "three-source and four-line method" in the design and harvest of anterolateral lower leg perforator flaps. Methods This study was a retrospective study of case series. From August 2023 to July 2024, the patients with hand or foot wounds who met the inclusion criteria were admitted to Suzhou Ruihua Orthopedic Hospital, including 24 patients from the Department of Hand Surgery and 6 patients from the Department of Foot and Ankle Surgery. There were 22 males and 8 females, aged 18 to 58 years. After debridement, the single wound area ranged from 2.0 cm×1.5 cm to 15.0 cm×4.5 cm. By applying the "three-source and four-line method", the line connecting the fibular head and the tip of the lateral malleolus was defined as Line C, representing the surface landmark line of the fibula; Line B was defined as Line C shifted 1.5 cm anteriorly, representing the axis of the superficial peroneal artery perforator flap; Line A was defined as Line C shifted 3.0 cm anteriorly, representing the axis of the anterior tibial artery perforator flap; Line D was defined as Line C shifted 1.5 cm posteriorly, representing the axis of the peroneal artery perforator flap. Then the color Doppler ultrasound detector was employed to identify perforators from the three vascular origins along Lines A, B, and D, respectively. Accordingly, anterolateral lower leg perforator flaps were designed and harvested to repair the wounds. A total of 35 flaps were harvested, with the single flap area ranging from 2.5 cm×2.0 cm to 16.0 cm×5.0 cm. All the donor site wounds were closed by direct suturing. During surgery, the total number of actually used perforators, as well as the number, caliber, and vascular pedicle length of perforators from different sources were recorded; the vertical distances from the perforators' skin entry points to their corresponding axes were measured. After surgery, flap survival was observed. During follow-up, the color, texture, and appearance of the flaps and the scar condition of donor sites were recorded. At the final follow-up, the flap repair outcome was evaluated using the flap comprehensive rating scale, and the excellent and good rate of flap repair outcome was calculated. Results During surgery, a total of 38 perforators were actually used. Among them, 6 perforators originated from the anterior tibial artery, with a mean caliber of 0.47 mm, a mean vascular pedicle length of 4.33 cm, and a mean vertical distance from the perforators' skin entry point to the Line A of 0.48 cm. Twenty perforators originated from the superficial peroneal artery, with a mean caliber of 0.51 mm, a mean vascular pedicle length of 5.25 cm, and a mean vertical distance from the perforators' skin entry point to the Line B of 0.54 cm. Twelve perforators originated from the peroneal artery, with a mean caliber of 0.72 mm, a mean vascular pedicle length of 4.13 cm, and a mean vertical distance from the perforators' skin entry point to the Line D of 0.43 cm. After surgery, all flaps survived smoothly. Follow up for 6-15 months showed the flaps exhibited favorable color, soft texture, and no obvious bulkiness; only linear scars were left at the donor sites. At the final follow-up, the scores of flap comprehensive rating scale ranged from 82 to 94 points and the excellent and good rate of flap repair outcome was 100% (35/35). Conclusions The "three-source and four-line method" has the advantages of simple operation and accurate perforator localization. It is helpful for flexible preoperative design and safe intraoperative harvest of the anterolateral lower leg perforator flaps with high clinical application value. -
Key words:
- Surgical flaps /
- Perforator flap /
- Microsurgery /
- Wound repair /
- Three-source and four-line method
-
参考文献
(40) [1] 石岩,王腾,徐永清,等.数字化技术在胫前动脉穿支皮瓣修复手部创面中的应用[J].中华显微外科杂志,2022,45(2):167-170.DOI: 10.3760/cma.j.cn441206-20211116-00276. [2] 张韬,程俊楠,杨林,等.多穿支腓浅动脉穿支皮瓣修复手足创面的疗效[J].中华烧伤与创面修复杂志,2023,39(3):234-240.DOI: 10.3760/cma.j.cn501225-20220723-00305. [3] 余少校,周望高,陈国荣,等.显微削薄腓动脉穿支皮瓣修复手指背侧软组织缺损[J].中华显微外科杂志,2022,45(6):617-621.DOI: 10.3760/cma.j.cn441206-20220411-00071. [4] 石岩,徐永清,王腾,等.数字重建技术虚拟规划游离胫前动脉穿支皮瓣修复足踝创面[J].中华显微外科杂志,2024,47(6):630-634.DOI: 10.3760/cma.j.cn441206-20240513-00117. [5] 熊胜,巨积辉,金光哲,等.彩超定位下游离腓浅动脉穿支皮瓣修复手足部创面[J].中华手外科杂志,2018,34(6):418-420.DOI: 10.3760/cma.j.issn.1005-054X.2018.06.007. [6] 赵英波,胡琪,王兆庆,等.腓动脉穿支皮瓣联合阔筋膜游离移植修复手背复合组织缺损[J].中华手外科杂志,2025,41(2):120-123.DOI: 10.3760/cma.j.cn311653-20241008-00260. [7] 杨晓东,刘杨武,杨锦,等.腓浅动脉穿支皮瓣游离移植修复手部创面[J].中华手外科杂志,2014,30(2):84-86.DOI: 10.3760/cma.j.issn.1005-054X.2014.02.002. [8] 胡雷鸣,欧学海,魏登科,等.应用游离腓动脉穿支皮瓣修复足部小面积感染性溃疡创面[J].中华显微外科杂志,2019,42(3):246-249.DOI: 10.3760/cma.j.issn.1001-2036.2019.03.009. [9] 陈步国,张松,潘勇,等.腓动脉近端穿支皮瓣修复手足部中小型创面的临床治疗效果[J].中华手外科杂志,2023,39(6):565-568.DOI: 10.3760/cma.j.cn311653-20230104-00004. [10] 袁辉宗,史增元,尹维刚,等. 胫前动脉前肌间隔穿支为蒂的岛状皮瓣的应用解剖[J]. 中国临床解剖学杂志,2011,29(3):249-251,255. DOI: 10.13418/j.issn.1001-165x.2011.03.016. [11] 李贤海,周建东,许亚军.带胫前动脉穿支的腓动脉穿支皮瓣修复前中足背创面[J].中华显微外科杂志,2020,43(5):464-468.DOI: 10.3760/cma.j.cn441206-20191215-00382. [12] 张伟,梁高峰,贾宗海,等.应用游离腓动脉穿支皮瓣修复老年患者指背感染性溃疡创面[J].中华显微外科杂志,2025,48(1):45-49.DOI: 10.3760/cma.j.cn441206-20240701-00163. [13] 张韬,杨林,程俊楠,等.“ABC”三线定位穿支方法在游离小腿前外侧穿支皮瓣的应用[J].中华显微外科杂志,2023,46(1):70-75.DOI: 10.3760/cma.j.cn441206-20220530-00107. [14] 肖飞鹏,柳志锦,刘胜哲,等.综合评价量表在股前外侧皮瓣修复术后疗效评价中的应用[J].中国美容整形外科杂志,2021,32(6):348-351.DOI: 10.3969/j.issn.1673-7040.2021.06.010. [15] 石岩,何晓清,杨曦,等.CT血管造影检查结合三维重建辅助设计腓浅动脉穿支皮瓣修复手部创面的疗效[J].中华创伤杂志,2021,37(6):501-507.DOI: 10.3760/cma.j.cn501098-20210202-00105. [16] LiSJ,ChengH,FangX,et al.Modified reversed superficial peroneal artery flap in the reconstruction of ankle and foot defects following severe burns or trauma[J].Burns,2017,43(4):839-845.DOI: 10.1016/j.burns.2016.12.003. [17] ChenYP,ZhongHY,YangR,et al.Optimizing localization accuracy in peroneal artery perforator sequential flap transplantation with digital subtraction angiography and high-frequency ultrasound[J].J Plast Surg Hand Surg,2025,60:46-50.DOI: 10.2340/jphs.v60.42954. [18] DeeringAJ, HarrahPA, WonBW, et al. Chimeric osteocutaneous free flap solution to variation in vascular anatomy[J]. Plast Reconstr Surg Glob Open,2025,13(1):e6443. DOI: 10.1097/GOX.0000000000006443. [19] 谢志平,庄跃宏,郑和平,等.腓血管蒂腓骨嵌合组织瓣设计的解剖学基础[J].中国临床解剖学杂志,2014,32(3):259-263.DOI: 10.13418/j.issn.1001-165x.2014.03.006. [20] HaY, YeoKK, PiaoY, et al. Peroneal flap: clinical application and cadaveric study[J]. Arch Plast Surg,2017,44(2):136-143. DOI: 10.5999/aps.2017.44.2.136. [21] LykoudisEG,KoutsourisM,LykissasMG.Vascular anatomy of the integument of the lateral lower leg: an anatomical study focused on cutaneous perforators and their clinical importance[J].Plast Reconstr Surg,2011,128(1):188-198.DOI: 10.1097/PRS.0b013e3182174303. [22] 李匡文,唐举玉,刘昌雄,等. 腓动脉穿支皮瓣的应用解剖[J]. 中国临床解剖学杂志,2011,29(4):382-385. [23] PapadimasD,ParaskeuopoulosT,AnagnostopoulouS.Cutaneous perforators of the peroneal artery: cadaveric study with implications in the design of the osteocutaneous free fibular flap[J].Clin Anat,2009,22(7):826-833.DOI: 10.1002/ca.20847. [24] KazemiK,SaadiF,JavanshirK,et al.Reliability of musculoskeletal ultrasonography for peri-ankle muscles in subjects with unilateral chronic ankle instability[J].J Bodyw Mov Ther,2021,27:565-572.DOI: 10.1016/j.jbmt.2021.04.018. [25] 李友,唐林峰,熊胜,等.游离多块小腿前外侧穿支皮瓣一期修复单手多指创面[J].中华显微外科杂志,2024,47(3):307-311.DOI: 10.3760/cma.j.cn441206-20230909-00031. [26] 郭全伟,赵强,程贺云,等.游离小腿同一供区多块腓浅动脉穿支皮瓣修复手部多处热压伤狭长创面的效果观察[J].中华手外科杂志,2024,40(4):356-359.DOI: 10.3760/cma.j.cn311653-20231207-00095. [27] 程贺云,巨积辉,赵强,等. CDU精准定位下游离一侧多个小腿外侧穿支皮瓣修复手指不同部位多个创面的效果[J]. 中华烧伤与创面修复杂志,2026,42(2):1-7. DOI: 10.3760/cma.j.cn501225-20241210-00484. [28] StoccoC,MurphyDC,GargiuloM,et al.Superficial peroneal nerve accessory artery (SPNAA) flap for head and neck reconstruction: a cadaveric anatomical study and retrospective case series review[J].J Plast Reconstr Aesthet Surg,2021,74(7):1524-1533.DOI: 10.1016/j.bjps.2020.11.012. [29] KimJS,SonDG,ChoiTH,et al.An anatomic study of the superficial peroneal nerve accessory artery and its perforators, and clinical application of superficial peroneal nerve accessory artery perforator flaps[J].Ann Plast Surg,2008,60(6):710-716.DOI: 10.1097/SAP.0b013e3180cab77f. [30] 程贺云,张韬,巨积辉,等.Flow-through腓浅动脉皮瓣修复手指伴指掌侧固有动脉缺损创面[J].中华显微外科杂志,2021,44(4):369-373.DOI: 10.3760/cma.j.cn441206-20210111-00011. [31] 徐永清,何晓清,陈雪松,等.手和足部创面修复时四种吻合血管的皮神经营养血管穿支皮瓣的选择[J].中华显微外科杂志,2020,43(4):331-337.DOI: 10.3760/cma.j.cn441206-20200218-00068. [32] ScaglioniMF,KuoYR,ChenYC.Reconstruction of distal hand and foot defects with the free proximal peroneal artery perforator flap[J].Microsurgery,2016,36(3):183-190.DOI: 10.1002/micr.22364. [33] PouletV,PrevostA,CavallierZ,et al.Fibula free flap perforasomes: vascular anatomical study and clinical applications[J].Surg Radiol Anat,2022,44(5):637-644.DOI: 10.1007/s00276-022-02953-4. [34] KimNG,LeeKS,ChoiTH,et al.Aesthetic reconstruction of lower leg defects using a new anterolateral lower leg perforator flap[J].J Plast Reconstr Aesthet Surg,2008,61(8):934-938.DOI: 10.1016/j.bjps.2007.06.006. [35] 杨晓东,刘杨武,杨锦,等.削薄腓浅动脉穿支皮瓣游离移植修复前足创面[J].中华显微外科杂志,2013,36(2):123-125.DOI: 10.3760/cma.j.issn.1001-2036.2013.02.008. [36] 程贺云,巨积辉,赵强,等.腓浅动脉穿支皮瓣在拇指和手指瓦合再造术中的临床应用[J].中华显微外科杂志,2023,46(6):631-636.DOI: 10.3760/cma.j.cn441206-20230714-00120. [37] 徐永清.小腿穿支皮瓣在中国的临床应用及进展[J].中华显微外科杂志,2020,43(6):521-534.DOI: 10.3760/cma.j.cn441206-20200527-00243. [38] YangX,ZhangG,LiuY,et al.Vascular anatomy and clinical application of anterolateral leg perforator flaps[J].Plast Reconstr Surg,2013,131(4):534e-543e.DOI: 10.1097/PRS.0b013e3182827675. [39] ShiY, XuY, FanX, et al. Three-dimensional digitalized virtual planning of free anterior tibial artery perforator flap for repairing soft tissue defects in extremities[J]. World J Surg,2023,47(7):1821-1827. DOI: 10.1007/s00268-023-06970-1. [40] 周健,郑玉岑,陈伟,等.携带神经的腓动脉穿支皮瓣修复腕部电烧伤后期神经缺损的临床效果[J].中华烧伤与创面修复杂志,2024,40(9):835-841.DOI: 10.3760/cma.j.cn501225-20240520-00187. -
图 1 采用“三源四线法”和彩色多普勒超声定位小腿前外侧穿支
注：C线为腓骨小头与外踝尖的连线,即腓骨的体表标志线；B线为C线向前侧平移1.5 cm所得,即腓浅动脉穿支皮瓣的轴心线；A线为C线向前侧平移3.0 cm所得,即胫前动脉穿支皮瓣的轴心线；D线为C线向后侧平移1.5 cm所得,即腓动脉穿支皮瓣的轴心线；图中“×”为彩色多普勒超声定位的穿支位置
图 2 应用“三源四线法”设计和切取腓动脉穿支皮瓣修复例1患者右手创面的效果。2A.清创术后患者右手示、中指创面；2B.术中应用“三源四线法”设计皮瓣；2C.术中探测到2条穿支,均来源于腓动脉；2D.皮瓣切取后拟转移至受区；2E.皮瓣修复后即刻受区外观；2F.将供区创面直接拉拢缝合后；2G.术后9个月,皮瓣色泽良好、外形无明显臃肿；2H.术后9个月,供区遗留线性瘢痕
图 3 应用“三源四线法”设计和切取腓浅动脉穿支皮瓣修复例2患者左手创面的效果。3A.清创术后患者左手示指创面；3B.术中应用“三源四线法”设计皮瓣；3C.术中探测到替代穿支后,调整皮瓣切取位置；3D.术中溯源结果显示替代穿支来源于腓浅动脉；3E.皮瓣修复后即刻受区外观；3F.将供区创面直接拉拢缝合后；3G.术后10个月,皮瓣色泽良好、外形无明显臃肿；3H.术后10个月,供区遗留线性瘢痕
-
